Description
Engine Model: YTO YT4A4Z-24 | Dimensions (mm): 6200×2100×2800 | Power (kW): 85 | Rated load (kg): 2700 | Operating weight (kg): 6500
Standard Features:
- 85 kW YTO YT4A4Z engine
- 4WD
- 16/70-24 tires
Optional Features:
- DF Cummins 4BT3.9-C100 engine
- Quick hitch
- Air conditioning
| Specification | Data |
| Standard Engine: | YTO YT4A4Z-24 |
| Optional Engine: | CUMMINS / YU CHAI / CHANG CHAI |
| Bucket Capacity (cbm): | 1.0–1.2 |
| Rated Load (kg): | 2700 |
| Overall Weight (kg): | 6500 |
| Dumping Clearance (mm): | 3600 |
| Rated Power (kW): | 85 |
| Rated Speed (rpm): | 2400 |
| Wheel Base (mm): | 2580 |
| Wheel Thread (mm): | 1695 |
| Dimensions L×W×H (mm): | 6515×2100×2950 |
| Standard Tire: | 16/70-24 |
| Max. Driving Speed (km/h): | 20–30 |
