Description
CATEGORY PARAMETER UNIT VALUE
General Fuel Type Diesel
Load Capacity kg 2,500
Load Center mm 500
Lift Lift Height mm 3,000
Full Free Lift Height mm 100
Fork Dimension mm 1070x122x40
Mast Tilting Angle F/R Deg. 6/12
Dimensions Min. Turning Radius mm 2,240
Ground Clearance mm 120
Overhead Guard Height mm 2,160
Front Overhang mm 450
Total Length (With Fork) mm 3,650
Total Length (W/O Fork) mm 2,580
Total Width mm 1,160
Mast Extended Height mm 4,220
Mast Lowered Height mm 2,060
Wheelbase mm 1,600
Tread Front/Rear mm 970/970
Service Weight kg 3,880
Performance Max. Travel Speed (Full) km/h 19
Max. Lift Speed (Full) mm/s 500
Max. Traction Power (Full) kN 18
Max. Gradeability % 20
Tyres Front 7.00-12-12PR
Rear 6.00-9-10PR
Powertrain Battery V/Ah 12/80
Motor Model Xinchai 490
CATEGORY PARAMETER UNIT VALUE
Motor Power kW 40
Transmission Hydraulic/Mechanical
Operating Pressure MPa
catalog
https://www.2material.com/wp-content/uploads/2026/02/forkliftcatalog.pdf
