Description
General Fuel Type Diesel
Load Capacity kg 3,000
Load Center mm 500
Lift Lift Height mm 3,000
Full Free Lift Height mm 100
Fork Dimension mm 1070x125x45
Mast Tilting Angle F/R Deg. 6/12
Dimensions Min. Turning Radius mm 2,400
Ground Clearance mm 135
Overhead Guard Height mm 2,165
Front Overhang mm 490
Total Length (With Fork) mm 3,770
Total Length (W/O Fork) mm 2,700
Total Width mm 1,225
Mast Extended Height mm 4,265
Mast Lowered Height mm 2,060
Wheelbase mm 1,700
Tread Front/Rear mm 1000/970
Service Weight kg 4,350
Performance Max. Travel Speed (Full) km/h 20
Max. Lift Speed (Full) mm/s 480
Max. Traction Power (Full) kN 20
Max. Gradeability % 20
Tyres Front 28×9-15-12PR
Rear 6.50-10-10PR
Powertrain Battery V/Ah 12/80
Motor Model Xinchai 490
CATEGORY PARAMETER UNIT VALUE
Motor Power kW 40
Transmission Hydraulic/Mechanical
Operating Pressure MPa 18.5
catalog
https://www.2material.com/wp-content/uploads/2026/02/forkliftcatalog.pdf
