Description
Specification
| Specification | Data |
|---|---|
| Transport Dimension L×W×H (mm): | 5920×2250×3770 |
| Overall Operating Weight (kg): | 8200 |
| Wheel base (mm): | 2200 |
| Min. Ground Clearance (mm): | 300 |
| Bucket Capacity (m³): | 1 |
| Breakout Force (kN): | 54 |
| Loading Lifting Capacity (kg): | 2500 |
| Bucket Dumping Height (mm): | 2740 |
| Bucket Dumping Distance (mm): | 1015 |
| Digging Depth (mm): | 52 |
| Backhoe Capacity (m³): | 0,3 |
| Max. Digging Depth (mm): | 4280 |
| Swing Angle of Excavator Grab (°): | 190 |
| Max. Pulling Force (kN): | 56 |
| Engine Model: | YC4A105Z-T20 |
| Cylinder – Inside Diameter × Stroke: | 4-102×120 |
| Rated Power (kW): | 75 |
| Rated Speed (r/min): | 2200 |
| Min. Fuel Consumption (g/km·h): | 230 |
| Max. Torque (N·m): | 380 |
| Displacement (L): | 4,4 |
| Tyre Model: | 14-17.5 / 19.5L-24 |
| Pressure of Front Wheel (MPa): | 0,4 |
| Pressure of Back Wheel (MPa): | 0,223 |
DIMENSION DRAWING
CERTIFICATES
https://www.2material.com/wp-content/uploads/2025/06/CE.pdf
CATALOG
https://www.2material.com/wp-content/uploads/2025/06/WOLF-Catalog-2025-New-1_compressed.pdf
