Description
Engine Model: Yanmar 3TNV70 Euro5 | Dimensions: 3053×850–1050×2458 mm | Power: 10,3 kW | Rated load: xxx kg | Operating weight: 1200 kg
| Specification | Data |
|---|---|
| Engine | |
| Model | Yanmar 3TNV70 Euro5 10.3 kW / 2200 rpm |
| Type | Direct injection, water cooled, natural intake |
| No. of cylinder | 3 |
| Fuel tank capacity (L) | 15 |
| Hydraulic oil tank capacity (L) | 13 |
| Travel speed (km/h) | 1.5 / 3.2 |
| Swing speed (r/min) | 11.5 |
| Max. climbing degree (%) | 0.58 |
| Arm digging force (kN) | 6 |
| Bucket digging force (kN) | 10 |
| Overall Dimensions | |
| Overall length (mm) | 3053 |
| Overall width (mm) | 850 / 1050 |
| Overall height (to top of boom) (mm) | 1035 |
| Overall height (to top of cab) (mm) | 2458 |
| Counterweight ground clearance (mm) | 404 |
| Min. ground clearance (mm) | 120 |
| Tail swing radius (mm) | 550 |
| Track ground length (mm) | 1080 |
| Track length (mm) | 1296 |
| Track width (mm) | 850 |
| Track gauge (mm) | 670 / 870 |
| Track shoe width (mm) | 180 |
| Machine weight (kg) | 1200 |
| Operating Range | |
| Max. digging height (mm) | 3018 |
| Max. dumping height (mm) | 2039 |
| Max. digging depth (mm) | 1809 |
| Max. vertical wall digging depth (mm) | 2233 |
| Max. digging reach (mm) | 3439 |
| Max. digging reach at ground level (mm) | 3390 |
